| 原厂 | Molex | 制造商型号 | 85510-5020 |
|---|---|---|---|
| 供应商 |
Element14 CN
英国仓
|
供应商型号 | 2060717 |
| 类型 | 模块化连接器-未分类 | 批号 | -- |
| 包装数 | -- | 包装 | -- |
| 产品描述 | Modular Connectors / Ethernet Connectors VERT SMT 8/8 RJ45 W/ TABS | ||
| 规格参数 | 数值 |
|---|---|
| RoHS | Details |
| USOC Codes | RJ45 |
| Number of Positions | 8 Position |
| Number of Ports | 1 Port |
| Performance Category | Cat 3 |
| Termination Style | SMD/SMT |
| Shielding | Unshielded |
| Current Rating | 1.5 A |
| Voltage Rating | 125 VDC |
| Color | Black |
| Series | 85510 |
| Contact Plating | Gold |
| Gender | Female |
| Housing Material | Thermoplastic |
| Mounting Angle | Vertical (Top Entry) |
| Contact Material | Tin |
| Flammability Rating | UL 94 V-0 |
| Pitch | 1.02 mm |
| Maximum Operating Temperature | + 85 C |
| Minimum Operating Temperature | - 40 C |
| Product Type | Modular Connectors / Ethernet Connectors |
| Factory Pack Quantity | 1148 |
| Subcategory | Modular Connectors / Ethernet Connectors |
| Part # Aliases | 0855105020 |
| Unit Weight | 0.110478 oz |
