| 原厂 | Amphenol | 制造商型号 | USBFTV7PE2G |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | ANFE-5077006 |
| 类型 | USB/DVI/HDMI连接器 | 批号 | -- |
| 包装数 | 10 | 包装 | -- |
| 产品描述 | USB - A USB 2.0 Receptacle Connector 4 Position Panel Mount | ||
| 规格参数 | 数值 |
|---|---|
| Connector Type | USB - A |
| Number of Contacts | 4 |
| Gender | Receptacle |
| Specifications | USB 2.0 |
| Mounting Type | Panel Mount |
| Mounting Feature | Bulkhead - Front Side Nut |
| Termination | Solder |
| Features | Backshell, Circular Threaded Coupling |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Operating Temperature | -40°C ~ 85°C |
| Number of Ports | 1 |
| Current Rating | - |
| Voltage - Rated | - |
| Mating Cycles | 500 |
| Shielding | - |
| Contact Finish | - |
| Shell/Shielding Material | Aluminum |
| Material Flammability Rating | - |
| Insulation Color | - |
