| 原厂 | TDK | 制造商型号 | B82144A2476J |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | EPCO-0033616 |
| 类型 | 固定值电感器 | 批号 | -- |
| 包装数 | 1500 | 包装 | -- |
| 产品描述 | 47mH Unshielded Wirewound Inductor 30mA 230 Ohm Max Axial | ||
| 规格参数 | 数值 |
|---|---|
| Type | Wirewound |
| Material - Core | Ferrite |
| Inductance | 47mH |
| Tolerance | ±5% |
| Current Rating | 30mA |
| Current - Saturation | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 230 Ohm Max |
| Q @ Freq | 40 @ 79.6kHz |
| Frequency - Self Resonant | 180kHz |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Frequency - Test | 10kHz |
| Mounting Type | Through Hole |
| Package / Case | Axial |
| Size / Dimension | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) |
| Height - Seated (Max) | - |
