| 原厂 | XP Power | 制造商型号 | EML15US24-E |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | XPPW-0021300 |
| 类型 | 板安装AC/DC转换器 | 批号 | -- |
| 包装数 | 1 | 包装 | -- |
| 产品描述 | AC/DC CONVERTER 24V 15W | ||
| 规格参数 | 数值 |
|---|---|
| Type | Enclosed |
| Number of Outputs | 1 |
| Voltage - Input | 85 ~ 264 VAC |
| Voltage - Output 1 | 24V |
| Voltage - Output 2 | |
| Voltage - Output 3 | |
| Voltage - Output 4 | |
| Current - Output (Max) | 630mA |
| Power (Watts) | 15W |
| Applications | Medical |
| Features | OCP, OVP, SCP |
| Operating Temperature | -20°C ~ 70°C (With Derating) |
| Efficiency | 82% |
| Mounting Type | Through Hole |
| Package / Case | 4-DIP Module |
| Size / Dimension | 2.56" L x 1.31" W x 0.96" H (65.0mm x 33.3mm x 24.4mm) |
