| 原厂 | Hirose Electric Co Ltd | 制造商型号 | MS-180 |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | HIRO-0063041 |
| 类型 | 同轴连接器-连接器 | 批号 | -- |
| 包装数 | 5 | 包装 | -- |
| 产品描述 | CONN COAX JACK STR 50 OHM SMD | ||
| 规格参数 | 数值 |
|---|---|
| Series | MS-180 |
| Connector Style | Coaxial Switch - 2.24mm Plug Dia |
| Connector Type | Receptacle, Female Socket |
| Contact Termination | Solder |
| Shield Termination | Solder |
| Impedance | 50 Ohm |
| Mounting Type | Surface Mount |
| Mounting Feature | - |
| Cable Group | - |
| Fastening Type | Snap-On |
| Frequency - Max | 11GHz |
| Number of Ports | 1 |
| Features | Internal Switch |
| Housing Color | Gold |
| Ingress Protection | - |
| Includes | - |
| Body Material | Brass |
| Body Finish | Gold |
| Center Contact Plating | Gold |
| Dielectric Material | Liquid Crystal Polymer (LCP) |
| Operating Temperature | -40°C ~ 85°C |
| Center Contact Material | Copper Alloy |
| Mating Cycles | 100 |
| Insertion Loss | 0.3dB |
