| 原厂 | Delta Electronics | 制造商型号 | AFB0624H-A |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | DLTA-0000098 |
| 类型 | DC风扇 | 批号 | -- |
| 包装数 | 1 | 包装 | -- |
| 产品描述 | FAN AXIAL 60X25.4MM 24VDC WIRE | ||
| 规格参数 | 数值 |
|---|---|
| Series | AFB |
| Voltage - Rated | 24VDC |
| Size / Dimension | Square - 60mm L x 60mm H |
| Width | 25.40mm |
| Air Flow | 23.4 CFM (0.655m³/min) |
| Static Pressure | 0.211 in H2O (52.6 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | - |
| Noise | 34.0 dB(A) |
| Power (Watts) | 2.16W |
| RPM | 4250 RPM |
| Termination | 2 Wire Leads |
| Ingress Protection | - |
| Operating Temperature | - |
| Approvals | CE, CSA, UL, VDE |
| Weight | 0.176 lb (79.83g) |
| Current Rating | 0.090A |
| Voltage Range | 14 ~ 27.6VDC |
| Material - Frame | Plastic |
| Material - Blade | Plastic |
| Lifetime @ Temp. | - |
