| 原厂 | EATON | 制造商型号 | DCM-3/4 |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | EATN-0044909 |
| 类型 | 专用电路保护 | 批号 | -- |
| 包装数 | 3 | 包装 | -- |
| 产品描述 | FUSE CRTRDGE 750MA 600VAC/VDC | ||
| 规格参数 | 数值 |
|---|---|
| Fuse Type | Cartridge |
| Current Rating | 750mA |
| Voltage Rating - AC | 600V |
| Voltage Rating - DC | 600V |
| Response Time | Fast |
| Applications | Electrical, Industrial |
| Features | |
| Class | |
| Approvals | CSA, UL |
| Operating Temperature | |
| Breaking Capacity @ Rated Voltage | 100kA AC, 50kA DC |
| Mounting Type | Holder |
| Package / Case | 5AG, 10mm x 38.1mm |
| Size / Dimension | 0.406" Dia x 1.500" L (10.30mm x 38.10mm) |
