| 原厂 | NKK Switches | 制造商型号 | IS15SBFP4B |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | NKKS-0047835 |
| 类型 | 可编程开关 | 批号 | -- |
| 包装数 | 8 | 包装 | -- |
| 产品描述 | SMARTSWITCH COMPACT WHITE LED | ||
| 规格参数 | 数值 |
|---|---|
| Series | SmartSwitch™ |
| Type | Pushbutton, LCD |
| Display Mode | Black and White, FSTN Positive |
| LED Color | White, Super Bright |
| Viewing Area | 13.0mm L x 10.7mm W |
| Face Size | 19.0mm L x 18.0mm W |
| Pixel Format | 36 x 24 |
| Circuit | SPST-NO |
| Switch Function | Off-Mom |
| Contact Rating @ Voltage | 0.1A @ 12VDC |
| Supply Voltage | 3.0 ~ 5.5VDC |
| Mounting Type | Through Hole |
| Termination Style | PC Pin |
| Operating Temperature | 0°C ~ 40°C |
| Operating Force | 2.2 Newtons |
| LED Forward Current | 20mA |
| LED Forward Voltage | 3.6VDC |
| Travel Range | 1.8mm |
| Style | Compact |
