| 原厂 | Artesyn Embedded Technologies | 制造商型号 | ADNB025-24-1PM-C |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | ASTN-0012533 |
| 类型 | 外接AC/DC转换器 | 批号 | -- |
| 包装数 | 1 | 包装 | -- |
| 产品描述 | AC/DC CONVERTER 24V 60W | ||
| 规格参数 | 数值 |
|---|---|
| Series | ADNB-C |
| Type | Enclosed |
| Number of Outputs | 1 |
| Voltage - Input | 88 ~ 264 VAC |
| Voltage - Output 1 | 24V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 2.5A |
| Power (Watts) | 60W |
| Applications | ITE (Commercial) |
| Voltage - Isolation | 4.242kV |
| Efficiency | 87% |
| Operating Temperature | -20°C ~ 70°C (With Derating) |
| Features | Adjustable Output, DC Input Capable, Universal Input |
| Mounting Type | DIN Rail |
| Size / Dimension | 3.90" L x 1.57" W x 3.54" H (99.0mm x 40.0mm x 90.0mm) |
| Minimum Load Required | No |
| Approvals | CE, cULus, UR, TUV |
