| 原厂 | COSEL | 制造商型号 | DHS250B24 |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | COHS-0007448 |
| 类型 | 板安装DC/DC转换器 | 批号 | -- |
| 包装数 | 1 | 包装 | -- |
| 产品描述 | DC DC CONVERTER 24V | ||
| 规格参数 | 数值 |
|---|---|
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 200V |
| Voltage - Input (Max) | 400V |
| Voltage - Output 1 | 24V |
| Voltage - Output 2 | |
| Voltage - Output 3 | |
| Voltage - Output 4 | |
| Current - Output (Max) | 10.5A |
| Power (Watts) | |
| Voltage - Isolation | 3kV |
| Applications | ITE (Commercial) |
| Features | Remote On/Off, OCP, OTP, OVP |
| Operating Temperature | -40°C ~ 100°C (With Derating) |
| Efficiency | 88% |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP Module |
| Size / Dimension | 2.40" L x 2.30" W x 0.50" H (61.0mm x 58.4mm x 12.7mm) |
| Supplier Device Package | |
| Control Features |
