| 原厂 | Bel Power Solutions | 制造商型号 | HP1001-9RTG |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | POW1-0008034 |
| 类型 | 外接DC/DC转换器 | 批号 | -- |
| 包装数 | 1 | 包装 | -- |
| 产品描述 | DC/DC CONVERTER 5.1V 122W | ||
| 规格参数 | 数值 |
|---|---|
| Type | Enclosed, Conformal Coated |
| Voltage - Input (Min) | 12.5V |
| Voltage - Input (Max) | 154V |
| Number of Outputs | 1 |
| Voltage - Output 1 | 5.1V |
| Voltage - Output 2 | |
| Voltage - Output 3 | |
| Voltage - Output 4 | |
| Current - Output (Max) | 18A |
| Power (Watts) | 122W |
| Applications | ITE (Commercial), Railway |
| Operating Temperature | -40°C ~ 71°C (With Derating) |
| Efficiency | 90.5% |
| Mounting Type | Chassis Mount |
| Package / Case | |
| Size / Dimension | 6.47" L x 4.37" W x 0.80" H (164.0mm x 111.0mm x 20.32mm) |
