| 原厂 | COSEL | 制造商型号 | SUW101212BP |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | COHS-0002192 |
| 类型 | 板安装DC/DC转换器 | 批号 | -- |
| 包装数 | 1 | 包装 | -- |
| 产品描述 | DC DC CONVERTER +/-12V 24V | ||
| 规格参数 | 数值 |
|---|---|
| Type | Isolated Module |
| Number of Outputs | 2 |
| Voltage - Input (Min) | 9V |
| Voltage - Input (Max) | 18V |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | -12V |
| Voltage - Output 3 | 24V |
| Voltage - Output 4 | |
| Current - Output (Max) | 450mA, 450mA |
| Power (Watts) | 11W |
| Voltage - Isolation | 500V |
| Applications | ITE (Commercial) |
| Features | |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Efficiency | 86% |
| Mounting Type | Surface Mount |
| Package / Case | 7-SMD Module, Gull Wing |
| Size / Dimension | 1.54" L x 0.83" W x 0.26" H (39.2mm x 21.0mm x 6.5mm) |
| Supplier Device Package | |
| Control Features |
