| 原厂 | Taoglas Limited | 制造商型号 | FXP14.09.0100A |
|---|---|---|---|
| 供应商 | chip 1 stop | 供应商型号 | TAOG-0000068 |
| 类型 | RF天线 | 批号 | -- |
| 包装数 | 25 | 包装 | -- |
| 产品描述 | RF ANT 850MHZ/900MHZ FLAT PATCH | ||
| 规格参数 | 数值 |
|---|---|
| Frequency Group | Wide Band |
| Frequency (Center/Band) | 850MHz, 900MHz, 1.7GHz, 1.8GHz, 1.9GHz, 2.1GHz |
| Frequency Range | |
| Antenna Type | Flat Patch |
| Number of Bands | 6 |
| VSWR | 2.5 |
| Return Loss | -7dB, -12dB, -8dB, -9dB, -9dB, -8dB |
| Gain | 2dBi, 1.5dBi, 3dBi, 2.5dBi, 2dBi, 2.5dBi |
| Power - Max | |
| Features | |
| Termination | Connector, MMCX Male |
| Ingress Protection | |
| Mounting Type | Adhesive |
| Height (Max) | 0.004" (0.10mm) |
| Applications | CDMA, GSM |
