| 原厂 | TRACO Power | 制造商型号 | TDL 2-4822 |
|---|---|---|---|
| 供应商 |
Element14 HK
新加坡仓
|
供应商型号 | 2812933 |
| 类型 | 板安装DC/DC转换器 | 批号 | -- |
| 包装数 | -- | 包装 | -- |
| 产品描述 | DC DC CONVERTER +/-12V 2W | ||
| 规格参数 | 数值 |
|---|---|
| Type | Isolated Module |
| Number of Outputs | 2 |
| Voltage - Input (Min) | 36V |
| Voltage - Input (Max) | 75V |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | -12V |
| Voltage - Output 3 | |
| Voltage - Output 4 | |
| Current - Output (Max) | 83mA, 83mA |
| Power (Watts) | 2W |
| Voltage - Isolation | 1.5kV |
| Applications | ITE (Commercial) |
| Features | SCP |
| Operating Temperature | -40°C ~ 70°C |
| Efficiency | 84% |
| Mounting Type | Through Hole |
| Package / Case | 7-DIP Module, 5 Leads |
| Size / Dimension | 0.55" L x 0.55" W x 0.31" H (14.0mm x 14.0mm x 8.0mm) |
| Supplier Device Package | |
| Control Features |
