| 原厂 | Infineon | 制造商型号 | IFX1763XEJ V50 |
|---|---|---|---|
| 供应商 | A7B060 货源来自认证的授权分销商，供应商商务原因匿名交易；质量参照易库易平台相关保证条款。 | 供应商型号 | IFX1763XEJ V50 |
| 类型 | 线性稳压器 | 批号 | -- |
| 包装数 | 2500 | 包装 | -- |
| 产品描述 | LDO Voltage Regulators INDUSTRIAL STANDARD PROD | ||
| 规格参数 | 数值 |
|---|---|
| RoHS | Details |
| Mounting Style | SMD/SMT |
| Package / Case | PG-DSO-8 |
| Output Voltage | 5 V |
| Output Current | 500 mA |
| Number of Outputs | 1 Output |
| Quiescent Current | 30 uA |
| Input Voltage MAX | 20 V |
| Input Voltage MIN | 5.5 V |
| Output Type | Fixed |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Load Regulation | 16 mV |
| Series | IFX1763 |
| Dropout Voltage | 320 mV |
| Dropout Voltage - Max | 450 mV |
| PSRR / Ripple Rejection - Typ | 65 dB |
| Line Regulation | 1 mV |
| Moisture Sensitive | Yes |
| Product Type | LDO Voltage Regulators |
| Factory Pack Quantity | 2500 |
| Subcategory | PMIC - Power Management ICs |
| Part # Aliases | IFX1763XEJV50XUMA1 SP000938802 |
